MDT - Rain detector, Outdoor installation on a wall, integrated BCU
-15%
Out-of-Stock
CHF191.50
CHF162.78
Tax included
Outdoor installation, surface mounting
Out-of-Stock
description
Outdoor installation, surface mounting
function
- Built-in, automatic heating
- Operation of the STV-640/STC self-serial self-release heating
- or 24VDC external power supply
- Current consumption of heating is <100mA
- 5m bus connection cable
- Stainless steel attachment angle included in the delivery
- Dimensions (L x H x D): 67mm x 67mm x 29mm
- Integrated bus coupling unit
- 3-year warranty
Technical specifications
- Measured data Rain
- KNX TP-256 Interface Specifications
- Application software available ETS 3/4/5
- KNX bus connection 0.8mm Ø, solid core
- Knx bus power supply
- Power consumption via the KNX typ bus. < 0.3W**
- Operating temperature -20 to + 70°C
- IP Enclosure 45
- Dimensions control unit (L x H x D) 67mm x 67mm x 29mm
Specifications
| Protocol | IP KNX |
|---|---|
| Type | Accessories for Smarthome gateways Gateways/Antennas Module |
-
