Sunricher - Converter 2 in 1 Zigbee to Dali 0/1-10V
Zigbee converter to Dali, based on Zigbee 3.0
The SR-2121-ZG is a Zigbee converter to Dali. It has a relay of 5A with tracking of electricity consumption.
It can search and pair with the Zigbee network and be controlled from the interface of your compatible home automation box or ZigBee gateway but it also works without home automation box.
Based on the Zigbee 3.0 standard, it can be linked and controlled by up to 30 Zigbee remotes supporting the touchlink option. It also supports the new Zigbee Green Power feature and can bind and be controlled to up to 20 Zigbee Green Power remotes directly without a Zigbee hub or gateway.
Several settings are possible via DIP Switch, for example to choose the DALI DT6 or DT8 mode, the color type, addresses or the DALI group, etc.
TECHNICAL FEATURES
- Food: 110-240 VAC
- Sign: ZigBee 2.4Ghz
- DALI Exit: Max 50mA
- Exit 0/1-10V: Max 20mA.
- Relay release: Max 5A.
- Range: up to 30m
- Dimensions: 80 x 36 x 20 mm
-
