FIBARO - Z-Wave+ smart switch for Roller Shutter (FIBARO Walli Roller Shutter)

FIBARO WALLI Z-WAVE+ SMART WALL SWITCH ROLLER SHUTTER

FIBARO Walli Roller Shutter is a smart switch designed for quick installation in flush-mounted boxes.

UNIQUE DESIGN AND EXCEPTIONAL TECHNOLOGY

The full set of FIBARO smart outlets and switches based on Z-Wave technology will give your home versatile intelligence. The look of the range is inspired by a pearl - its timeless sophistication and beautiful shape that will complement any interior.

LED RING THAT MATCHES YOUR HOME

Choose your favourite colour
Select the colour of the LED ring to suit your preference.

Double backlight button
Use two colours of backlight wherever you want - one colour on the bottom and a different one on top to indicate the exact status of the device.

An overview of the energy consumption
Monitor the amount of energy consumed by your household appliances.

RELIABLE COMPONENTS AND EYE-CATCHING DETAILS

At FIBARO, quality and unique design always go hand in hand. The Walli line was designed to increase the comfort and safety of your family for many years.

PRESS HOWEVER YOU LIKE

Configure the button on Walli switches to take full advantage of its amazing capabilities.

A single press to turn on the light, a double press to turn it off, a triple press to turn on the “Fun” setting, a long press for a light intensity of 60%. It's up to you.

COMPATIBLE WITH PRODUCTS FROM OTHER MANUFACTURERS

FIBARO Walli is compatible (with adapters) with the front units of other manufacturers: GIRA - System 55, Legrand - Céliane Schneider - Odace. If you want to keep the outlets and switches you already own, equip them with a smart flush-mounted part and enjoy the smart home functions without needing to replace the front unit.

VOICE MANAGEMENT FOR THE ENTIRE HOME

Walli smart switches and outlets are fully compatible with the famous voice assistants, Google Wizard and Amazon Alexa. Easy and comfortable voice management throughout the home.

BE WITH YOUR HOME WHEREVER YOU ARE

The FIBARO Home Center mobile application allows you to manage smart switches and plugs with your smartphone, tablet or smartwatch. Keep everything under control like a boss.

CONTROLLED ENERGY CONSUMPTION

Have an in-depth view of your home, analyse the energy consumption of your household appliances and optimise your expenses as you see fit.

TAKE A STEP INTO THE FUTURE

The FIBARO Walli series includes classic, non-smart switches and outlets to keep a consistent look for your interior. Choose the ones you want and enjoy the unique features and design.

Warning, this switch requires neutral to operate.

FUNCTIONS

• Manage appliances and settings with one click.
• Remote management of electrical appliances.
• Manage appliances using voice commands.
• Adapt the light ring to user preferences.
• Electrical equipment failure notifications.
• Monitor energy consumption

TECHNICAL SPECIFICATIONS

• Power supply: 110-230V 50 / 60Hz
• Nominal load: 13A per channel, 16A total
• Load types supported: incandescent tube lights, electronic transformers, magnetic transformers, LED
• Radio frequency: 868.0–868.6 MHz
• Range: up to 40m indoors (depending on the terrain and building structure)
• Max. transmission power: + 6dBm
• Operating temperature: 0–35°C
• Ambient humidity: 10-95% relative humidity with no condensation
• For installation in boxes: Ø = 60mm, depth ≥ 40mm
• Dimensions (H x L x D): 86 x 86 x 51mm
