SMLIGHT - USB Ethernet POE Adapter Zigbee and Thread CC2674P10 + EFR32MG26

Introduction

The SMLIGHT SLZB-MR4 is a next-generation multi-radio USB Ethernet PoE adapter designed to offer maximum compatibility and total flexibility in managing smart home networks. Equipped with the powerful Texas Instruments CC2674P10 and Silicon Labs EFR32MG26 chipsets, it combines Zigbee 3.0 and Thread (Matter-over-Thread) in a single device. This solution allows for the construction of an open, scalable smart home environment independent of proprietary solutions, while ensuring exceptional stability and range.

Thanks to its advanced connectivity (USB-C, Ethernet, and PoE 48V), high-performance antennas, intuitive web interface, and multiple configuration options, the SLZB-MR4 meets the needs of smart home enthusiasts and professional integrators alike. Pre-flashed and ready to use, it is compatible with Zigbee2MQTT and ZHA, and can be used in coordinator or router mode.

Key Features

• Multi-radio support: Zigbee 3.0 and Thread (Matter-over-Thread) simultaneously.
• Full compatibility with Zigbee2MQTT and ZHA.
• Usable as a coordinator or router depending on configuration.
• Flexible connection: Ethernet, USB-C, or PoE 48V (low consumption, max. 1.5W).
• Simple firmware updates via web interface.
• SLZB-OS: advanced management (integrated VPN, scripts, multilingual, OTA, dashboard).
• External antennas +5 dB for stable and extended range.
• Convenient interface: 6 status LEDs + multifunction button (mode, reset, switch).
• Flexible installation: wall-mounted, DIN rail, adhesive, or screwed.
• Factory pre-flashed: ready to use immediately.

Technical Specifications

• Reference: SLZB-MR4
• Chips:
  • Texas Instruments CC2674P10 (+20 dBm, integrated PA, Zigbee & Thread)
  • Silicon Labs EFR32MG26 (+20 dBm, Zigbee & Thread)
• Supported Protocols:
  • Zigbee 3.0 (Zigbee2MQTT & ZHA)
  • Thread (Matter-over-Thread)
  • Wi-Fi & Bluetooth via integrated ESP32
• Connectivity: USB-C (power & data), stable Ethernet (LAN8720), PoE 48V.
• Power Supply: PoE 802.3af or USB-C 5V DC (low consumption, max. 1.5W).
• Antennas:
  • 2 high-performance external SMA antennas (2.4 GHz)
  • Internal PCB antenna for Wi-Fi/Bluetooth
• Firmware: Compatible with TI Z-Stack (CC2674P10) and SL Ember/EZSP (EFR32MG26). OTA updates or via web interface.
• Indicators: 6 independent LEDs (main SoC, CC2674P10, EFR32MG26) + multifunction button.
• Casing: Durable and ventilated ABS, compact. Wall-mounted, DIN rail, or adhesive installation.
• Compatibilities:
  • Zigbee2MQTT
  • ZHA (Home Assistant)
  • Open Thread Border Router (Matter-over-Thread)
  • Support for open ecosystems (Home Assistant, Jeedom, Domoticz…)
